Name: Serial Connection Water Meter Test Equipment Semi Automatic
Brand: HNMC
Price: 1 USD

Brand Name : HNMC

Model Number : LJS15-25

Place of Origin : China

MOQ : 1

Payment Terms : L/C, T/T, Western Union, MoneyGram

Delivery Time : 4-8weeks

Packaging Details : Wooden Package

Price : Negotiable

Supply Ability : 10 sets per month

Test Meter Size : DN15-25

Meter Positions : 8Nos

Operation mode : Semi-automatic

Accuracy : 0.2%

Size : 4400*1860*2200

Number of Meter : DN15×8,DN20×5,DN25×4,

Storage Tank : 3m³

Pressure Tank : 0.5m³

Contact Now

DN15/25 8 meters serial connection semi-automatic water meter test bench

Water meter test bench(Manual)
Caliber	15-25
Model	In series	Test
Size(mm)	440018602200
Number of Meter	DN15×8,DN20×5,DN25×4,	Single
Glass Rotameter	DN15/25/50/80	DN15/25
Vessel	10L/20L 100L/500L	10L/20L 100L/500L
Class	0.20%	0.20%
Flow Range	0.016m³/h~40m³/h	0.016m³/h~40m³/h
Optional
Pump	Q=50m³/h H=50m N=15Kw		Q=50m³/h H=50m N=15Kw
Storage Tank	3m³		3m³
Pressure Tank	0.5m³		0.5m³
Pressure-tight test	0-2MPa		0-2MPa
Liquied level photoelectrical	DC5V,4		DC5V,4
Controller of Photoelectric Sensors	Receive photoelectric signal and control valve		Receive photoelectric signal and control valve

DN15/25

8 meters serial connection semi-automatic water meter test bench

Configuration list

Sr.	Item	specification	origin	Qty.
1	work capacitor and drainage bottom valve	66L S stainless steel (2mm)	NINGBO	1set
2	Glass rotameter	LZB-15S	NINGBO	1pcs
2	Glass rotameter	LZB-25S	NINGBO	1pcs
3	Meter holder	DN25 S=80mm stainless steel	MINGTAI	1set
4	Straight pipe	DN15×8,DN20×6,DN25×5 meter straight pipe ≥2D,(wall thickness3.5mm)	MINGTAI	1set
5	Working table and accessories	Working table rack, rack, connect pipe, flange, elbow bend etc.	MINGTAI	1 set
6	High speed photography module	MTSX-1	MINGTAI	10 set
7	PC	2.8G or better /1G/160G/ 20`` LCD screen	HUNTKEY	1 set
8	software	Quality testing method software	MINGTAI	1 set
9	Control box	Exclusive use for quality testing method	MINGTAI	1set
10	Communication controller	Exclusive use for quality testing method	MINGTAI	1set
11	Steady flow device (filtration)	500L	MINGTAI	1set
12	Pressure sensor	0－2.5MPa	MIKE	2 set
13	Temperature sensor	0－50℃	MIKE	1set
14	Pressure retaining valve components	P≥2MPa	MINGTAI	1set
15	pump	Q=6.3m³/h H=50m N=3Kw	SOUTH	1 set
16	tank	1000L	MINGTAI	1set
17	transducer	3KW	MISUBISHI	1 set
18	Air compressor	0.05 m3/min-0.8	AOTUSI	1 set
19	Water supply pipe	Wall thickness 3.5mm or better	MINGTAI	1 set
